Hardware description, 1 front panel – Asus GigaX1008N User Manual
Page 4
3
2. Hardware description
2.1 Front panel
The GigaX1005N/1008N front panel comes with light emitting diode (LED)
indicators that display the status of your switch. Refer to Table 1 for the
LED status, color and description.
Figure 2.1. GigaX1005N front panel
Figure 2.2 GigaX1008N front panel
Table 1 LED indicators
LED
Status
Color
Description
Power
ON
Green
The power is ON
LNK/ACT ON
Green
Device connected to port
Blinking
Transmitting data
OFF
No device connected
