4
2.2 Rear panel
GigaX1005N:
The GigaX1005N rear panel comes with five 10/100Mbps RJ-45 Ethernet
ports and one power connector.
Figure 2.3. GigaX1005N Rear Panel
GigaX1008N:
The GigaX1008N rear panel comes with eight 10/100Mbps RJ-45 Ethernet
ports and one power connector.
Figure 2.4. GigaX1008N Rear Panel
Power Input
1 2 3 4 5
0.3A Max. 50-60Hz
Power Input
AC 100V-240V 0.1A,50-60Hz
1 2 3 4 5 6 7 8
