4-20 Chapter 4: BIOS setup
4.5 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
4.5.1 CPU Temperature / MB Temperature [xxx�C/xxx�F] [xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and motherboard
temperatures. Select Ignore if you do not wish to display the detected temperatures.
4.5.2 CPU / Chassis Fan Speed [xxxx RPM] or [Ignore] /
[N/A]
The onboard hardware monitor automatically detects and displays the CPU, chassis,
and power fan speeds in rotations per minute (RPM). If the fan is not connected to the fan speeds in rotations per minute (RPM). If the fan is not connected to the
motherboard, the field shows N/A. Select Ignore if you do not wish to display the detected
speed.
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
