INSTALLATION
This antenna is provided with type BZ-mount. The whip is fastened to the
mount by means of our standard ball-joint and wing screw system. The
adjustable ball-joint ensures that the whip can always be mounted in a
vertical position independent of the angle of the installation spot.
The BZ-mount is particularly well suited for mounting on car-roofs because
of its ability to be installed exclusively with access from the outside. The BZ-
Mount for roof thickness from 2 mm to 7.5 mm must be mounted from the
inside.
However, the antenna can be installed anywhere on the car, as the BZ-
mount is equally well suited for mounting on e.g. trunk or wing.
1. INSTALLATION DIMENSIONS
2. INSTALLATION STEPS
Do not use sealer on rubber gasket or other places.
PROCOM A/S reserve the right to amend specifications
without prior notice.
02/12/11
