CONTROL ELEMENTS
The elements are:
1. USB
Slot
2. IR—sensor (for remote control)
3. Power indication light
The elements are:
1.
Aerial input (75Ω)
2. Aerial output (Loop through)
3. Digital audio output (coaxial)
4. SCART Output (TV)
5. SCART Input (VCR)
6. Power input
1. 3. 2.
Front Panel
Rear Panel
1. 2. 3. 4. 5. 6.
