Procom GPS 2000 User Manual
Gps 2000
GPS 2000
Active Receiving Antenna for the 1575 MHz NAVSTAR
GPS Satellite Navigational System for Maritime and
Landmobile Use
DESCRIPTION
Flat-pack GPS-antenna for fixed installations.
Full hemispherical coverage.
Built-in high gain, low noise amplifier.
Right-hand circular polarization (RHCP).
Available in black or white, see model survey.
3 V or 5 V supply voltage (12 V available on request).
DC supply via RF-connector.
EMC tested to IEC 801 and IEC 255.
Provided with FME (male), TNC (female) connector, or models
with permanently attached 0.15 m cable with FME (male) connector,
see model survey.
Wide range of FME-accessories available.
GPS 2000B
GPS 2000W
GPS 2000B-P0.15
GPS 2000W-P0.15
FME-VERSION
TNC-VERSION
Models with permanently attached cable
MOUNTING
The gasket should be entirely supported by the mounting plane.
Do not use sealer on rubber gasket or other places.
