UAD Powered Plug-Ins Manual - 310 - Chapter 29: Ocean Way Studios
Cut Filters Independent High Cut and Low Cut filters can be enabled on each mi-
crophone. Click the switch to toggle the filter state. The filter is active
when the switch is illuminated. The cutoff frequency and filter slope
varies for each of the microphones, as shown in
Table 25 below.
Polarity Invert This switch inverts the polarity (“phase”) of the microphone. The signal
polarity is inverted when the switch is illuminated.
Polarity is especially useful when more than one microphone pair is enabled.
See
“Phase Considerations” on page 300 for related information.
Mute Mute turns off the microphone pair so it is no longer heard. Click the
switch to toggle the mute state. When mute is active, the switch is illu-
minated, and the mic placement indicators are hidden from the Posi-
tion Display.
Tip: To quickly solo any microphone pair, shift-click any Mute switch. When
a Mute switch is shift-clicked, that mic is un-muted and the other mics are
muted.
Balance Balance sets the position in the stereo panorama. When the plug-in
is used in a mono-in/mono-out configuration, this control is locked
in the center position.
Tip: To quickly return to the center position, click the BALANCE
text label.
Table 25. Microphone Cut Filter values
High Cut Filter
(6 dB/Octave)
Low Cut Filter
(12 dB/Octave)
Near 10 kHz Near 50 Hz
Mid 8 kHz Mid 75 Hz
Far 6 kHz Far 150 Hz
