Configuring
the Remote Preamp
CFG (ConFiGure) Press the -/+ keys simultaneously to enter the configuration menu (CFG). Use the - key to scroll through
the menu items (shown below). When the desired menu item is reached, use the + key to scroll through
the available settings (shown below next to each menu item). Press the -/+ keys simultaneously again to
cancel the CFG menu. The CFG display will turn itself off after no adjustment has been made for 1
minute.
Menu item Settings
C IN operating level c.H* Hi level (+4dBu nominal)
c.L Lo level (-10dBV nominal)
TALK mic level tL._ Press + key to cycle mic levels in 3dB steps (3* is default, 1
is softest, 5 is loudest)
TALK mode t.Ph* talk to Phones, TALK MIC OUT will always be active although
the mic volume tracks the level of the CUE VOL knob
t.JS talk to TALK MIC OUT Jack, Switched - NO talk to phones
t.JA talk switch disabled, TALK MIC OUT Jack Always on
Phones mute mode Ph.A* CUE OUT Always on (ignores SPKR MUTE)
Ph.F CUE OUT mute Follows SPKR MUTE switch
Ph.O CUE OUT mutes Opposite of SPKR MUTE switch
*The first settings in the menus above are factory CFG defaults, other default settings reset as shown
below:
rSt (reset) Hold the -/+ keys simultaneously for 2 seconds to reset the Remote Preamp to the factory default CFG
settings. This reverts the following controls: GAIN Trim: +18dBu, -4dB warning, 0 VU: -14dB from
maximum preamp output, REVERB: St.2 preset, sends from A and B enabled, EQ: LO and HI bands
zeroed, CUE IN TRIM: 0, SPKR OUT TRIM: -12
DCS:link TM connection between Controller and Base
Any standard CAT-5, CAT-5e or CAT-6 (Ethernet) cable may be used at any length up to 300ft/100meters. The
cable may be hot-plugged into either Controller or Base at any time with power turned on or off. The green LED next
to the DCS:link jack lights continuously when the Controller and Base are functioning properly. The LED blinks when
the DCS:link is unconnected or not functioning properly.
Powering the Remote Preamp
Simply connect your IEC power cable to an AC electrical outlet. The DCS remote Preamp has no power switch. The
orange LED on the Base Logo Panel lights to indicate the Base is receiving AC power. The Base provides power to the
Remote through the DCS:link cable.
WARNING! The DCS Remote Preamp operates under a fixed voltage and may be damaged by incorrect input
voltage! Depending on in what country your DCS Remote Preamp was purchased, it may be rated for 100V, 120V or
240V input. Use the DCS Remote Preamp only under power conditions from the region in which you purchased the
unit. Check underside of remote Preamp Base to check input voltage. Replace the fuse with the same type only.
