6-5
ONLY THOSE PARTS CIRCLED IN DRAWING AND/OR LISTED BELOW ARE STOCK ITEMS
ALL OTHERS ARE SPECIAL ORDER, NON-RETURNABLE
PARTS LIST - METER TIMER
REF PART No. DESCRIPTION
A 60354-13 Power Head Assy., Complete, L/Cover, NWS Series (Incl. Ref. Items 2-40)
D 13168-36X Brine Cam Assy. 6-36 lb. Salt (Incl. Ref. Items 26, 28-33)
E 14449-00X Control Valve Body Assy. (Incl. Ref. Items 41-84)
F 60102-00 Piston Kit (Incl. Ref. Items 45-49)
G 60125 Seal Kit (Incl. Ref. Items 50 & 51)
H 60084-50X Brine Valve Assy., 0.50 GPM (Incl. Ref. Items 55-84)
J 60022-50 Brine Line Flow Control Assy., 0.50 GPM, (Incl. Ref. Items 77-80)
K 60086 Meter Assy. (Incl. Ref. Items 85-93)
L 60049/18706X
60049/18706-02X 1" Bypass Valve Assy.
3/4" Bypass Valve Assy. (Optional)
1 22601X Valve Cover, Specify Model
23 18743 Motor, 120v/60 Hz
24 11384 Motor Mtg. & Ground Screw
38 14043 Flexible Cable
39 13547 Strain Relief
40 11842 Power Cord, 110V/60Hz
53 13304 Distributor Tube O-Ring
54 12281 Tank O-Ring
65 13497 Air Disperser
68 10914 Injector Throat - Specify Size
69 10227 Injector Screen
70 10913 Injector Nozzle - Specify Size
71 13303 Injector Cover O-Ring
72 13166 Injector Cover
73 13315 Injector Mounting Screw
74
12086
12088
Drain Line Flow Control Button:
Model 100 and 100M
Model 150, 150M,200 and 200M
75 13173 Drain Line Flow Control Retainer
76 13308 Drain Line Fitting
81 12767 Brine Line Screen
82 10332 Brine Line Tube Insert
83 10330 Brine Line Ferrule
84 10329 Brine Line Fitting Nut
90 13314 Adapter Coupling screw
91 13255 Adapter Clip
92 13821 Meter Body
93 13305 Meter Body O-ring
102 18706
18706-02 Adapter Yoke, 1" NPT
Adapter Yoke, 3/4" NPT
