PARANI-BCD100
Page 9 of 22
3. RF Characteristics
3.1 Basic Data Rate
3.1.1 Transmitter Performance
RF Characteristics
PVCC = 3.3V, 25°C Min Typ Max Bluetooth
Specification
Unit
Output power 16 18 19 ≤ 20 dBm
Power Density 16 18 19 ≤ 20 dBm
Power Control 3 4 6 2 ≤ step ≤ 8 dB
TX Output Spectrum-Frequency range 2402 - 2480 2400 ~2483.5 MHz
TX Output Spectrum-20dB Bandwidth - 900 - ≤ 1000 kHz
Adjacent
Channel Power F = F
0
± 2MHz - - -20 ≤ -20 dBm
F = F
0
± 3MHz - - -40 ≤ -40 dBm
F = F
0
± > 3MHz - - -40 ≤ -40 dBm
Modulation
Characteristics Δf1
avg
145 165 175 140 ≤ Δf1
avg
≤ 175 kHz
Δf2
avg
115 155 - Δf2
avg
≥ 115 kHz
Δf2
avg
/Δf1
avg
0.8 0.95 - (Δf1
avg
/Δf2
avg
) ≥ 0.8 -
Initial Carrier Frequency Tolerance -20 - 20 ≤ ±75 kHz
Carrier
Frequency Drift Drift rate -20 - 20 ≤ ±20 kHz/50µs
1 slot Freq Drift -25 - 25 ≤ ±25 kHz
5 slot Freq Drift -40 - 40 ≤ ±40 kHz
Table 3-1 Transmitter performance at basic data rate
3.1.2 Transceiver
RF Characteristics
PVCC = 3.3V, 25°C Min Typ Max Bluetooth
Specification
Unit
Out of band
Spurious
Emissions 0.030-1.000GHz -36 - - ≤ -36 dBm
1.000-12.75GHz -30 - - ≤ -30 dBm
1.800-5.100GHz -47 - - ≤ -47 dBm
5.100-5.300GHz -47 - - ≤ -47 dBm
Table 3-2 Transceiver at basic data rate
3.1.3 Receiver Performance
RF Characteristics
Temperature 25°C Min Typ Max Bluetooth
Specification
Unit
Sensitivity - Single slot packets (0.1%) - -90 -70 ≤ -70 dBm
Sensitivity - Multi slot packets (0.1%) - -90 -70 ≤ -70 dBm
C/I performance
at 0.1% BER co-channel - - -11 ≤ -11 dB
F = F
0
+ 1MHz - - 0 ≤ 0 kHz
