PARANI-BCD100
Page 11 of 22
3.2.2 Receiver performance
RF Characteristics
Temperature 25°C Min Typ Max Bluetooth
Specification
Unit
Sensitivity
at 0.01% BER π/4 DQPSK - -88 -70 ≤ -70 dBm
8DPSK - -85 -70 ≤ -70 dBm
BER floor performance - - -60 ≤ -60 dBm
C/I Performance
(co-channel at 0.1% BER) π/4 DQPSK - - 13 ≤ +13 dB
8DPSK - - 21 ≤ +21 dB
C/I
Performance
(Adjacent
Channel
Selectivity)
F = F
0
+ 1MHz π/4 DQPSK - - 0 ≤ 0 dB
8DPSK - - 5 ≤ +5 dB
F = F
0
– 1MHz π/4 DQPSK - - 0 ≤ 0 dB
8DPSK - - 5 ≤ +5 dB
F = F
0
+ 2MHz π/4 DQPSK - - -30 ≤ -30 dB
8DPSK - - -25 ≤ -25 dB
F = F
0
– 2MHz π/4 DQPSK - - -20 ≤ -20 dB
8DPSK - - -13 ≤ -13 dB
F ≥ F
0
+ 3MHz π/4 DQPSK - - -40 ≤ -40 dB
8DPSK - - -33 ≤ -33 dB
F ≤ F
0
– 5MHz π/4 DQPSK - - -40 ≤ -40 dB
8DPSK - - -33 ≤ -33 dB
F = F
π/4 DQPSK - - -7 ≤ -7 dB
8DPSK - - 0 ≤ 0 dB
Maximum input level
at 0.1% BER π/4 DQPSK -20 - - ≥ -20 dBm
8DPSK -20 - - ≥ -20 dBm
Table 3-5 Receiver performance at enhanced data rate
