open
close
hot
cold
User Instructions
The spray function is activated by pressing
the diverter bar. After releasing the diverter,
the mixer returns automatically to the stream
function.
Check Valve Maintenance
The check valve should be removed and checked
yearly.
Technical Data
Operating pressure:
max. 145 psi
Recommended operating pressure:14.5 - 75 psi
Test pressure: 22 psi
Hot water temperature: max. 80° C
Recommended hot water temp.: 120° - 140° F*
Rate of flow: 2.2 gpm
Hole size in countertop 1 1/2”
Maximum countertop depth 2 /8”
Protection against back-siphonage provided by inte-
gral check valve and vacuum breaker.
Hansgrohe single lever mixers can be used
together with instantaneous water heaters if the
flow pressure is at least 22 psi.
If the flow of water is reduced, clean the filter located
between hose and handspray.
