Page 3
Installation
*Some models may have different component as illustrated below.
※
Hand Dryer Unit
w/o Top Cover
Accessories
Model is subject to change without further notification.
Mounting Bracket
Screws and Vandal Resist Hex Wrench
Template
Installation Manual
(φ4.5Ч30) Ч6
(M4Ч6) Ч2
Bracket (Top)
Bracket (Bottom)
Installation
position
Installation
position
Wiring Hole
Water Tray
Chassis Assy
Filter
Filter case
Top cover
Drain tray
Power Cable
Filter case
Wall surface
Sensor
Air nozzles
Junction box
(Connection type)
Color : White,Black,Green
Size : AWG16Ч3
