2
28420001
27418001
Installation Considerations:
The 27418001 shower arm requires a 1/2"
male threaded nipple, recessed 3/8"
behind the finished surface of the ceiling.
The 27410001 shower arm requires 1/2"
male threaded nipple, extending 5/8"
outside the surface of the finished wall.
Hansgrohe recommends that the Raindance
Air Royale showerhead be installed with the
Ecostat thermostatic mixing valve. Do not install
this showerhead with a pressure balancing
valve.
A 12 mm allen wrench (not included) is useful
for installing the ceiling mount arm. 12 mm
allen wrenches are available at hardware and
auto parts stores.
Technical Specification
Flow rate 2.5 gpm
Suggested Layouts
Two-feature installation with Ecostat thermostatic
mixer and Trio diverter.
Three-function shower with Ecostat thermostatic mixer,
3/4" volume control, and Quattro diverter.
27410001
