AN-30 Speaker Monitor Owners Manual
AN-30 TEChNICAL SPECIFICATIONS
(Specifications Subject to Change Without Notice)
Anchor Audio customer service
800.262.4671
For AdditionAL inFormAtion
visit www.anchoraudio.com
4
Rated Power Output 30 Watts
Max SPL @ Rated Power 100 dB @ 1 meter
Frequency Response 100Hz - 15KHz ±3dB
Speaker Type 4.5” Neodymium woofer
Line Out Jack
line level, 3.5 mm – stereo
Line In Jack line level, 3.5 mm – stereo & 1/4” phone – mono
DC Input Jack 12-24 V, 2A Min.
Dimensions (HWD) 5.5” x 5.5” x 6.5” (14 x 14 x 16.5 cm)
Weight 1.5 pounds / 0.68 Kg
The AN-30 speaker may be the smallest system in the Anchor Audio product line but
it’s big in power with 109 dB of sound from 30 watts of rated power output. The AN-30
can cover a typical sized conference room or classroom with ease. The AN-30 is so
lightweight, at under two pounds, that it mounts effortlessly to a wall or ceiling bracket.
It has a shielded magnet speaker that won’t cause interference when installed near video
monitors.
Applications for this product include foreground and background music systems, music
playback, full-range paging and instructional applications. Combine an AN-30 and
projector in a classroom for the perfect audio visual solution.
A variety of mounting accessories are available for wall, ceiling and speaker stand
installations.
AN-30 DESCRIPTION & APPLICATIONS
