Data Sheet
GG1/GG2/GGS/EG1/EG3
Basis and Expansion Units
Combination Options:
The devices can be combined as follows:
GG2
+
EG1
GG1
+
EG1
GG2
+
2 x
EG3
GG1
+
2 x
EG3
GGS
+
EG1
GGS
+
2 x
EG3
The connection between the basis units and the expansion units is made with plug-in
ribbon cable.
The system bus must be terminated on the ends with a bus termination connector
with resistance.
Date:
20.08.2008 Page:
5/5 Author:
HS
Document
No.:
DB_BPxxx_338x_01
