Data Sheet
GG1/GG2/GGS/EG1/EG3
Basis and Expansion Units
25-pin D-sub connector to connect to the distributor
1
U-connector for 48 V DC operating voltage
2
Solder bridge to distribute the operating voltage 48 V DC
3
Solder bridges for cable screen grounding on the DVS side
4
Solder bridges for additional voltage supply for the call stations
with
+/-48
V
5
6
Connectors to connect an expansion backplane or to take bus
termination connectors
9-pin D-Sub connector to connect to the amplifier outlet
7
Solder bridges for disaster allocation
8
Solder bridges for disaster groups
9
Solder bridges for V100 output voltage
10
Technical Data:
Weight:
Approx. 2040 g incl. module frame
Installation Height: 3HE (133 mm) incl. module frame
Installation Height: 19 inch (482 mm) incl. module frame
Installation Depth:
240 mm
Date:
20.08.2008 Page:
4/5 Author:
HS
Document
No.:
DB_BPxxx_338x_01
© 2008 ProCom, All rights and technical changes reserved
