Data Sheet
DTA-012 / 030 / 048 / 066 / 084 / 114
Desk Call Station with Call Signal
www.dvs-21.de
The DTA desk call station consists of the following components:
o
The three-part grey-white desk housing made of ABS
o
The aluminium mounting plate
o
The electrical components:
-
Gooseneck microphone (standard part for call station with call signal,
mounted in top)
-
4 W/6 W loudspeaker (mounted on aluminium plate)
-
Motherboard with 4 W call station amplifier (mounted in housing base)
-
Keypad circuit board with 30 keys (mounted on aluminium plate)
- Keypad circuit board with 18/36/54 keys (mounted on aluminium plate)
Included with the product are:
-
DTA connecting cable 2.5 m
- Wall connection socket
A 4NSA module is required in the system in order to connect the call stations to the
DVS-21.
The analogue interface module 4NSA is connected to the wall connection socket by
4 or 6-wire cable and configured there according to the corresponding plug contacts.
The DTA connecting cable is plugged into the 15-pin D-sub connector of the DTA
and configured according to the corresponding plug contacts of the wall connection
socket.
Order Data:
Quantity of Illuminated
Buttons Model as Call
Station with Call
Signal Model as
Malfunction Alert
Panel
DTA-012 1.012 -
DTA-030 1.030 1.039
DTA-048 1.048 1.049
DTA-054 - 1.059
DTA-066 1.066 1.069
DTA-084 1.084 1.089
DTA-114 1.114 1.119
Date: 13.03.2009 Page: 3/6 Author: VS Document-No.: DB_DTA-12-114_1059_01
