Page 4
Data Sheet
CPU1
Processor Module
Technical Data:
Operating Voltage: +/-5 V (control)
Operational Current (+5 V):
200 mA
Operational Current (-5 V):
4 mA
Interfaces:
• 28 control outputs (card selection) for
(V24 to backplane)
addressing of the DVS-21 modules
• 48 PCM user channels
Interfaces:
• Port1: Serial interface for PC for system
(V.24 on the front)
configuration
• Port2: connection for DCF 77 (radio controlled
clock)
Temperature Range: 0 °C to 45 °C
Weight:
300 g
Installation Height: 3HE
Installation Width:
6TE
Date:
13.03.2009 Page:
4/4 Author:
HS
Document-No.:
DB_CPU1_2200_01
© 2008 ProCom, All rights and technical changes reserved
