Battery Powered (3V, DC)
Lloyd™ Sensor Urinal Flush Valve, Exposed - 1.0 GPF
To be specified:
Sensor Urinal Flush Valve
❒ Complete Set, Nickel Chrome Plated Finish
❒ Central Rough - TEY1DNC-42
Complete set supplied with:
■ 5/8" Vacuum Breaker
■ Spud Nut & Escutcheon
Meets the American disability Act Guidelines and ANSI A117.1
requirements for people with disabilities.
AUTOMATIC FLUSHING SYSTEM
TOTO, the world leader in advanced plumbing systems, provides sensor operated flush valves for facilities demanding the
finest sanitation equipment for busy restrooms. “Hands-free” technology effectively reduces unsanitary conditions from
unflushed fixtures.
FUZZY LOGIC MICROPROCESSOR
“Fuzzy logic” controlled flushing offers the ultimate water conservation without sacrificing performance. The new TOTO urinal
flush valves utilize a fuzzy logic control microprocessor which measures the duration and frequency of use, and flushes an appro-
priate volume (0.5 – 1.0 gpf). In facilities with periods of frequent use, water conservation is maximized with the use of fuzzy logic
technology.
CENTRAL ROUGH-IN
TOTO’s Lloyd™ sensor flush valve has a central rough-in.
TEY1DNC-42
SPECIFICATIONS
Product TEYIDNC–Complete set (5/8” V.B.) Central Rough, Chrome Plated Finish
Power supply Two AA alkaline batteries, 2-year life, based on 4000 cycles per month
Detection range Self-adjusting to environment
Water supply pipe 1/2” NPT
Discharge quantity Fuzzy logic adjusted flush volume at 28psi (0.5-1.0 GPF)
Urinal type Low consumption wash down and jetted flush design urinal
Trap seal protection Automatic flushing once every twenty-four (24) hours, if not used
Ambient temperature 33°-104°F (1°-40°C)
Supply water pressure
10 psi - 100 psi*
Warranty
Limited three (3) year warranty on all component parts. Details available upon request.
Listings
ASSE 1037
TOTO Model No. TEY1DNC-42 Automatic infrared sensor activated urinal flush valve. Heavy-duty zinc die cast cover with
nickel-chrome finish. Vandal resistant hex head screws. 1.0 gpf. Two AA alkaline batteries Included providing a 2-year life
at 4,000 cycles/month. Solenoid with self-cleaning mechanism. Automatic flush every twenty four hours if not used. Vacuum
breaker included with accessories.
SUGGESTED ENGINEERING SPECIFICATION:
These dimensions and specifications are subject to change without notice.
*Water pressures over 80 psi are not recommended for most plumbing fixtures.
