AUTOMATIC FLUSHING SYSTEM
TOTO, the world leader in advanced plumbing systems, provides sensor operated flush valves for facilities demanding the finest
sanitation equipment for busy restrooms. “Hands-free” technology effectively reduces unsanitary conditions from unflushed fixtures.
SELF-GENERATING POWER SYSTEM
TOTO’s new technology of automatic generator flush valves offer easy installation without the cost and downtime required to install
power supplies and wiring for each valve. A hydro-powered turbine charges the power supply during usage eliminating the need
for a battery replacement or consumption of external power for up to 10 years.
SUPERIOR PISTON VALVE
TOTO’s piston valve technology is a marked improvement over traditional rubber diaphragm type valves. Longer piston travel and SELF-
CLEANING 360° debris screen reduce common problems such as continuous running and flooding. The piston seat itself will not warp or
mis-seal thus, significantly reducing repair and maintenance costs. A micro-porous cup seal keeps the piston self-lubricated upon each
activation with the incoming water supply.
NEUTRAL ROUGH-IN
TOTO’s sensor flush valve has neutral rough-in, it can be
used as right or left rough-in with no modification.
FUZZY LOGIC MICROPROCESSOR
“Fuzzy logic” controlled flushing offers the ultimate water
conservation without sacrificing performance. The new
TOTO urinal flush valves utilize a fuzzy logic control
microprocessor with measures the duration and frequency
of use, and flushes an appropriate volume (less than 0.5
gpf). In facilities with periods of frequent use, water
conservation is maximized with the use of fuzzy logic
technology.
For optimal performance, we recommend using our 0.5 HEU
flushometers in conjunction with our 0.5 HEU commercial urinals.
To be specified:
Sensor Toilet Flush Valve
Complete Set, Nickel Chrome Plated Finish
TEU1LN12#CP (3/4" V.B.) - Left and Right Rough
TEU1LN22#CP (1-1/4" V.B.) - Left and Right Rough
Complete set supplied with:
Vacuum Breaker & Angle Stop Set - VB9CP-12
3/4" Angle Stop - 10077t4
3/4" Vacuum Breaker - 10075t2
Spud Nut & Escutcheon - 71051Nt5
Sweat Solder Kit - TH559EDVSJ1
Vacuum Breaker & Angle Stop Set - VB9CP-22
3/4" Angle Stop - 10077t4
1-1/4" Vacuum Breaker - 10075t5
Spud Nut & Escutcheon - 71051Nt5
Sweat Solder Kit - TH559EDVSJ1
Valve only, Nickel Chrome Plated Finish
TEU1LN#CP - Left and Right Rough
Z-4000-J - Adapter for Ground Joint Angle Stops
Meets the American Disabilities Act Guidelines and ANSI A117.1
requirements for people with disabilities.
TOTO’S ECOPOWER ® FLUSH VALVES
Sensor High Efficiency Urinal (HEU) Flush Valve, Exposed - 0.5 GPF
Commercial Line
TEU1LN12#CP
1
Infrared Sensor
2
Flushing
3
Flushing Every 12 Hours
The infrared sensor detects a
user standing in front of the
urinal within 2 ft (600mm). When the user stays in place
longer than 6 seconds then
moves away, the controller
sends a signal to the operating
unit to automatically trip the
flush valve. If urinal is not used, the system
automatically flushes every 12
hours after the last flush as a
maintenance and
hygienic precaution.
OPERATING PROCEDURE A sanitary environment without using the hands.
®
