· Install the outer sleeves to the hot
and cold valves. Measure each
outer sleeve to a point 3/8” from
the surface of the finished wall.
Mark the sleeve at this point. Cut
the sleeves. Install the inner
sleeve.
· The handle should be parallel
to the floor. If it is not, remove
the handle. Remove the handle
insert, turn it slightly and replace.
The handle should now be
parallel to the floor.
· Measure the inner sleeve to a
point 1⁄2” from the surface of the
finished wall. Mark and cut the
inner sleeve at this point. Place
the handle over the inner sleeve.
· Remove the handles.
