4
Put the tub filler on the rough (1).
Pivot the tub filler so that it faces the correct direction
().
Make sure that the tub filler is level (3).
Install the screws. Tighten them with an 8 mm Allen
wrench (4).
Seal the floor around the plaster shield with
waterproof sealant (1).
Lower the escutcheon to the floor ().
Put the black rubber washer in one end of the hose.
Attach this end to the tub filler.
Put the screen washer in the other end of the hose.
Attach this end to the hand shower.
Put the hand shower in the holder.
1
1
3
4
