Page 2
Strike Dimensions and Required Clearances
Door Preparation for Strike
931224_00(5)
#16 drill and
#12-24 tap
2 places
Suggested
cutout
Reinforce for strike
attachment as required
LHR shown
RHR opposite
C door
L
C strike
L
RHR door
shown inactive
1-7/16” minimum
clearance
5/8”
1-15/16”
3”
7/8”
3-7/8”
1-3/4”
6”
1/4”
5-1/4”
Minimum
clearance
2-3/8”
minimum
clearance
2-5/8”
1-1/4”
C strike
and
latch bolt
L
1” dia. minimum
clearance
2-3/8”
minimum
clearance
Strike
backbox
assembly
3-1/2”
1-1/16”
1-1/4”
3-7/8”
C of door
L
