English installation – Factory Direct Hardware Hansgrohe 11431 Axor Urquiola User Manual
Page 6
6
English
Installation – ½"
Requires ½" NPT male nipple recessed ⅜" behind
surface of finished wall.
(1) Wrap the threads on the nipple with Teflon tape.
(2) Install the mounting piece. Tighten using a ⁷⁄₁₆"
Allen wrench (not included).
(3) Seal the wall around the
mounting piece using waterproof
sealant.
Failure to seal the wall may result in
water damage.
(4) Install the spout.
Tighten the screw using a 3 mm Allen wrench.
1
4
3
2
