Installation
Position the faucet and sealing ring in place on the
mounting surface.
From below the mounting surface, install the friction
washer, metal washer and mounting nut. Tighten the
mounting nut by hand. Tighten the tensioning screws.
Install the pull rod.
Connect the supply hoses to the stops with 3/8”
compression fittings (not included). Use two
wrenches, as shown in the diagram, to keep the
supply hoses from twisting or becoming loosened
from the faucet.
Install the pop-up drain.
Turn on the water. Check all connections for
leaks.
Reset the high temperature limit stop, if desired.
sealing ring
friction washer
metal washer
mounting nut
tensioning screw
pull rod
