OUTSIDE TRIM FUNCTIONS

* “BE” (Blank Escutcheon) no cylinder used - lever always active
** “NL” (Night Latch) rigid lever - key retracts latch bolt
*** ”DT” (Dummy Trim) rigid lever for pull operation
**** “NL-OP” (Optional Pull) needs to be added

360L-BE*

360L-DT***

360T

33A/35A SERIES FINISHES

US3
US4
US10
US15
US26
US26D
US28
313AN

315AN

605
606
612
619
625
626
628
710

711

Polished Brass
Dull Brass
Dull Bronze
Satin Nickel
Polished Chrome
Dull Chrome
Anodized Alum. (Clear)
Anodized Alum. (313)
Dark Bronze
Anodized Alum. (Black)

U.S. Std

Reference

BHMA

Reference

Description

304L Strike (Bottom)

Panic or Fire

Exit Hardware

STRIKES

385A Strike (Bottom)

Standard Panic or Fire

Exit Hardware

338 Strike (Top) Standard

Panic or Fire Exit Hardware

283 Strike (Top)

Wood Frame

Screw Pkg 900285

Screw
964191
