2. Description
The spectrum tube power supply unit is intended
for the operation of spectrum tubes U41810 to
U41825. It provides for undisturbed and constant
illumination and increases the lifespan of the tubes
themselves. A clamp with a spring clip ensures that
spectrum tubes can be safely mounted and make
good contact. Full insulation of the clamps and a
protective window ensure safe operation.
The spectrum tube power supply unit with order
number U418001-115 is designed for a mains volt-
age of 115 V (±10%) while the version with order
number U418001-230 is for 230 V (±10%).
3. Accessories
List of available spectrum tubes
Spectrum tubes Cat. No.
Air U41810
Argon U41811
Bromine U41812
Carbon dioxide U41813
Chlorine U14814
Deuterium U41815
Helium U41816
Hydrogen U41817
Iodine U41818
Krypton U41819
Mercury U41820
Neon U41821
Nitrogen U41822
Oxygen U41823
Water vapor U41824
Xenon U41825
4. Technical data
Output voltage: 5000 V
Mains voltage: See rear of housing
230 / 115 V AC, 50/60 Hz
Fuse: T 1.0 A
Dimensions: 370 x 120 x 110 mm 3
Weight: 2.9 kg approx.
5. Operation
5.1 General information
• It is recommended that spectrum tubes be
handled with a cloth or gloves in order to
avoid greasy fingerprints.
• Do not insert or remove spectrum tubes unless
the spectrum tube control unit is switched off.
• Open the protective window by pulling on the
right upper or lower edge.
• To insert the spectrum tube into the power
supply, snap it into the lower tube clamp with
the spring clip.
• Push the tube gently downwards and fasten it
in place with the upper clamp.
• Close the protective window.
• Turn on the spectrum tube power supply.
• Use a spectroscope/spectrometer to observe
the spectral lines.
• Before removing the spectrum tube, turn off
the tube power supply and allow the tube to
cool.
• Open the protective window.
• Push the tube gently downwards and slip it out
of the upper clamp.
5.2 Changing the fuse
• Turn off the power switch and unplug the
mains plug.
• Unscrew the fuse holder on the back of the
stand base with a screwdriver.
• Replace the blown fuse with a fuse matching
the original and reinsert the holder in its
socket.
