INPUTS
Connectors:
Female XLR Pin 2 hot, pin 1 lift switch.
Type:
Electronically balanced/unbalanced, RF filtered.
Impedance:
Balanced > 20 kΩ, unbalanced > 10 kΩ.
Maximum Input Level:
>+30dBu balanced, > +26dBu unbalanced.
CMRR:
>100dB 20 Hz to 200 Hz, >80dB 200 Hz to 2 kHz, >60dB
2 kHz to 20 kHz.
OUTPUTS
Connectors:
Male XLR Pin 2 hot.
Type:
Transformer balanced/unbalanced, RF filtered.
Impedance:
Balanced 50Ω, unbalanced 25Ω.
Maximum Output Level:
Balanced >+30dBm (into 600Ω). Unbalanced (with UNBAL switch
engaged) >+24dBm (into 600Ω).
SIDECHAIN SEND (OUTPUT)
Connector:
Male XLR Pin 2 hot.
Type:
Unbuffered, hard-wired to INPUT, RF filtered.
SIDECHAIN RETURN (INPUT)
Connector:
Female XLR Pin 2 hot.
Type:
Electronically balanced/unbalanced, RF filtered.
Impedance:
Balanced >20 kΩ, unbalanced >10kΩ.
Maximum Input Level:
>+30dBu balanced or unbalanced.
SYSTEM PERFORMANCE
0.1dB Bandwidth:
20 Hz to 20 kHz +0/-0.1dB, no gain reduction, unity gain.
1.0dB Bandwidth:
<4 Hz to >40 kHz +0/-1.0dB, no gain reduction, unity gain.
Frequency Response:
<2 Hz to >200 kHz +0/-3.0dB, no gain reduction, unity gain.
Noise:
<-92dBu, unweighted, 20 Hz to 20 kHz measurement bandwidth.
Dynamic
Range:
>122dB
THD + Noise:
0.008% typical at +4dBu, 1kHz, unity gain.
0.05% typical at +30dBu, 1kHz, unity gain.
<0.1% any amount of compression up to 30dB, 1kHz
IMD:
<0.02% SMPTE 4:1, no gain reduction, unity gain.
Deviation From Linear Phase:
<1.0 degree, <10 Hz to 200 kHz, 30dB of compression.
Interchannel Crosstalk:
<-100dB, 20 Hz to 20 kHz.
VCA:
dbx
V8
™
VCA Dynamic Range:
>127dB
VCA THD + Noise:
0.006% typical at +4dBu, 1 kHz, unity gain.
Stereo Coupling:
True RMS Power Summing
™
.
COMPRESSOR
Threshold Range:
-40 to +30dBu
Ratio:
1:1
to
4:1
Threshold Characteristic:
Selectable OverEasy‚ or hard knee.
Attack/Release Modes:
Selectable Manual or Auto.
Manual Attack Time:
Scalable program-dependent. Typically 400dB/msec to 1dB/msec.
Manual Release Time:
Scalable program-dependent. Typically 4000dB/sec to 10dB/sec.
