Solder Column Interface Soldering Techniques (continued)
Tel: (800) 404-0204
www.ironwoodelectronics.com
•
See manufacturer’s recommendation for your specific application.
(6) Clean PCB with the flux manufacturers recommended process. The picture of the solder
connection is shown in Figures 4 and 5.
250
200
150
100
50
0
100 200 300 400 500
Preheat Flux Activation Reflow Cool-Down
<2°C
per Second
150 - 180 Seconds
<2°C
per Second
1° to 3°C
per Second
Time (seconds)
Temperature (°C)
Maximum Package Body Temperature
Solder Temperature Melting Point
Example 63/37 Reflow Profile
Figure 4: Magnified View of Solder
Connections
Figure 5: Solder Connections
