Smart Ride
COMPLETE DIGITAL AIR MANAGEMENT SYSTEM
LOWEST
“B”
MAX LIFT
“A”
ARM
LENGTH
“AL”
AXLE
GROUND
WHEEL
MID
TRA
VEL
“VL/2”
1. MEASURE
THE SUSPENSION
TRA
VEL
WITH
YOUR
AIR SYSTEM.
a. DETERMINE WHICH SUSPENSION LINK IS GOING
TO BE
ATT
ACHED
TO
THE HEIGHT
SENSOR
b. INFLA
TE
THE SUSPENSION
TO MAXIMUM PRESSURE OR MAXIMUM LIFT
.
c. MEASURE
THE DIST
ANCE FROM
THE FRAME SIDE LINK
PIVOT
POINT
OF
THE LINK
TO
THE GROUND.
d. WRITE DOWN
THIS MEASUREMENT
IN BOX "A".
e. DEFLA
TE
THE SUSPENSION
TO ITS LOWEST
POINT
.
f. MEASURE
THE DIST
ANCE FROM
THE SAME PIVOT
POINT
T
O
THE GROUND. WRITE DOWN
THIS MEASUREMENT
IN BOX
"B". g. SUBTRACT
“A”
AND “B”
TO GET
THE VER
TICLE LIFT
. WRI
TE
THIS DOWN IN BOX "VL".
h. RAISE
THE VEHICLE HALF W
AY
UP
SO
THA
T
THE FRAME SIDE PIVOT
IS EQUAL
T
O HALF OF "VL".
i. MEASURE
THE DIST
ANCE BETWEEN
THE PIVOT
BOL
TS O
N
THE LINK
AND WRITE
THIS DOWN IN BOX "AL".
