6.1 Alternative lubricants
Alternative lubricants:
Trade name and number Operating temperature
°C
Shell Alvania GC -15…+80
Shell Alvania EP00 -15…+80
Shell Tivela Compound A S) -20…+130
Neste Center Grease 00 EP -35…+100
Castrol EPL 00 -35…+100
MOBILITH SHC 007 S) -50…+230
S) Synthetic lubricant.
If the drive is operated for long periods in extremely cold conditions (colder than -25 ºC) or extremely hot
conditions (hotter than + 55 ºC), it is recommended that a synthetic lubricant be used.
7 Recommended tightening torques
Recommended tightening torques for screws and nuts
Tightening torque
Size Strength 8.8 Strength 10.9
Nm Ft lb Nm Ft lb
M4 2.7 2.0 4.0 2.9
M5 5.4 4.0 7.9 5.8
M6 9.3 6.8 14 10.3
M8 23 17.0 33 24
M10 45 33.0 66 48.5
M12 77 56.6 115 84.6
M14 125 92 180 132
M16 190 206 280 206
M18 275 202 390 287
M20 385 283 550 404
M22 530 390 750 552
M24 660 485 950 699
M27 980 721 1400 1030
M30 1350 993 1900 1398
8 Inspection and servicing intervals
The inspection and servicing interval for a drive is 12 calendar months for a crane in an 8-hour per day,
5-day per week work period, under normal environmental conditions (free from excessive dust, moisture,
and corrosive fumes). The inspection and servicing intervals of the drive could be defined by Safe
Working Periods (SWPs) if it is being monitored. If the Safe Working Periods is being monitored, then
the servicing interval must be carried out at the end of the Safe Working Period (SWP%) of the crane or
hoist, or by the end of the stated number of calendar months, whichever comes first. If the drive is being
used intermittently, it should be inspected before being used again.
F
If the duty is heavier, or the environment severe, service intervals should be shortened and more
frequent.
Only authorized or adequately-trained personnel may carry out service or repair work. If any defects or
abnormalities are observed, they must be investigated and corrective action must be taken in accordance
with the instructions.
