Table 17. Hoist Body Single Phase Power Supply Parts List
ITEM
PART
NUMBER
DESCRIPTION QTY
- 52315418 BODY & CONTROLS – 115V SINGLE PHASE – 16S 1
1 N/A MACHINED CASING 1
2 52308741 MOTOR FLANGE ASSEMBLY 1
3 52308742 GEAR COVER WITHOUT ROTARY LIMIT ASSEMBLY 1
4 52308768 GEAR & BRAKE COVER SEAL SET 1
5 52305510 BRAKE COVER SET – SINGLE PHASE UNITS ONLY 1
6 52316243 EXTENSION HOUSING – SINGLE PHASE UNITS ONLY 1
7 2218000 PUSHBUTTON SUSPENSION SET 1
8a 2213309001 BODY CAPACITY STICKER – ¼ TON 1
8b 2213309002 BODY CAPACITY STICKER – ½ TON 1
8c 2213309003 BODY CAPACITY STICKER – 1 TON 1
8d 2213309007 BODY CAPACITY STICKER – 250 KG 1
8e 2213309008 BODY CAPACITY STICKER – 500 KG 1
8f 2213309009 BODY CAPACITY STICKER – 1000 KG 1
9a 2229921 “C” TROLLEY COUPLING SET - PERPENDICULAR 1
9b 2229920 “C” TROLLEY COUPLING SET - PARALLEL 1
10a 2219955 TOP HOOK SET - PERPENDICULAR 1
10b 2219954 TOP HOOK SET - PARALLEL 1
11 52308832 RPT COUPLING SET 1
- 2212017 TOP HOOK SAFETY LATCH – STEEL PLATE TYPE 1
- 52308744 INSPECTION PORT CAP 1
- 2213445001 ELECTRICAL HAZARD WARNING STICKER 1
- 2213445002 ELECTRICAL WIRING INFORMATION STICKER 1
12 2406879009 LM05 SERIES II BODY BRANDING SET – SINGLE PHASE 1
