RANGE ACCURACY RESOLUTION
20nF 10pF
20uF
±(2.5%+20d)
10nF
200uF
±(5.0%+20d)
>100uF (only for
reference)
100nF
• Overload protection: 36V DC or AC peak value
WARNING: DO NOT input any voltage at this range for
safety!
2-2-7.TEMPERATURE(˚C)
RANGE ACCURACY RESOLUTION
(-20~1000)˚C < 400˚C±(1.0%+5d)
≥ 400˚C±(1.5%+15d)
1˚C
• Sensor: K-type thermocouple with banana plug
WARNING: DO NOT input any voltage at this range for
safety!
2-2-8.DIODE AND CONTINUITY TEST
Range Displaying value Test condition
Positive voltage
drop of diode
The positive DC current
is approx. 1mA, negative
voltage is approx. 3V
Buzzer sounds , the
resistance is less
than (70±20)Ω
open voltage is approx.
3V
• Overload protection: 250V DC or AC peak value
2-2-9. Triode hFE test
Range Displaying value Test condition
hFE NPN or PNP 0~1000 Basic current is
approx.10uA,Vce
is approx.3V
WARNING: DO NOT input any voltage at this range for
safety!
4
