SPE-11-8-125/C Page 2 of 28
I. Specification
ELECTRICAL
Frequency 2.4 ~ 2.5GHz, 4.9 ~ 5.8GHz
Peak Gain (straight) 3.3dBi 4.9dBi
Peak Gain (bend) 3.8dBi 5.5dBi
Average Gain (straight) -0.9dBi -1.5dBi
Average Gain (bend) -0.7dBi -0.0dBi
Efficiency (straight) 80% 71%
Efficiency (bend) 86% 83%
Polarization Linear
Impedance 50 Ohms
Radiation Pattern Omni
Input Power 2W max.
MECHANICAL
Antenna Length 194mm
Antenna Diameter 12.8mm
Antenna Body Material TPU
ENVIRONMENTAL
Temperature Range -40°C to 85°C
Humidity Non-condensing 65°C 95% RH
