MAX541/MAX542
+5V, Serial-Input, Voltage-Output, 16-Bit DACs
4 _______________________________________________________________________________________
__________________________________________Typical Operating Characteristics
(V DD = 5V, V REF = +2.5V, T A = +25°C, unless otherwise noted.)
0.50
0.45
0.40
0.35
0.30
0.25
0.20
-40 -20 0 20 40 60 80 100
MAX542-01
SUPPLY CURRENT (mA)
SUPPLY CURRENT
vs. TEMPERATURE
TEMPERATURE (°C)
0.35
0.34
0.33
0.32
0.31
0.30
0.29
0.28
0 1 2 3 4 5 6
MAX542-02
SUPPLY CURRENT (mA)
SUPPLY CURRENT
vs. REFERENCE VOLTAGE
REFERENCE VOLTAGE (V)
1.0
0.6
0.2
0
-0.2
-0.6
0.8
0.4
-0.4
-0.8
-1.0
-60 -20 20 60 100 140
MAX542-03
ZERO-CODE OFFSET ERROR (LSB)
ZERO-CODE OFFSET ERROR
vs. TEMPERATURE
TEMPERATURE (°C)
1.0
0.6
0.2
0
-0.2
-0.6
0.8
0.4
-0.4
-0.8
-1.0
-60 -20 20 60 100 140
MAX542-04
INL (LSB)
INTEGRAL NONLINEARITY
vs. TEMPERATURE
TEMPERATURE (°C)
+INL
-INL
1.00
0.50
0.25
0.75
0
-0.25
-0.50
-0.75
-1.00
0 10k 20k 30k 40k 50k 60k 70k
MAX542-07
INL (LSB)
INTEGRAL NONLINEARITY
vs. CODE
DAC CODE
1.0
0.6
0.2
0
-0.2
-0.6
0.8
0.4
-0.4
-0.8
-1.0
-60 -20 20 60 100 140
MAX542-05
DNL (LSB)
DIFFERENTIAL NONLINEARITY
vs. TEMPERATURE
TEMPERATURE (°C)
+DNL
-DNL
1.0
0.8
0.6
0.4
0.2
0
-0.2
-0.4
-0.6
-0.8
-1.0
-60 -20 20 60 100 140
MAX542-06
GAIN ERROR (LSB)
GAIN ERROR
vs. TEMPERATURE
TEMPERATURE (°C)
0.25
0.75
0.50
1.00
0
-0.25
-0.50
-0.75
-1.00
0 10k 20k 30k 40k 50k 60k 70k
MAX542-08
DNL (LSB)
DIFFERENTIAL NONLINEARITY
vs. CODE
DAC CODE
200
160
120
80
40
0
0 10k 20k 30k 40k 50k 60k 70k
MAX542-09
REFERENCE CURRENT (µA)
REFERENCE CURRENT
vs. CODE
DAC CODE
