MAX2056
800MHz to 1000MHz Variable-Gain
Amplifier with Analog Gain Control
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V CC to GND ...........................................................-0.3V to +5.5V
V CNTL to GND (with V CC applied)................................0 to 4.75V
Current into V CNTL Pin (V CC grounded) .............................40mA
All Other Pins to GND.................................-0.3V to (V CC + 0.3V)
RF Input Power (IN, IN_A, ATTN_OUT, OUT_A) ............+20dBm
RF Input Power (AMP_IN)...............................................+12dBm
θ
JA (natural convection)...................................................35°C/W
θ
JA (1m/s airflow) .............................................................31°C/W
θ
JA (2.5m/s airflow) ..........................................................29°C/W
θ
JC (junction to exposed paddle) ....................................10°C/W
Operating Temperature Range ...........................-40°C to +85°C
Storage Temperature Range .............................-65°C to +150°C
Junction Temperature ......................................................+150°C
Lead Temperature (soldering, 10s) .................................+300°C
AC ELECTRICAL CHARACTERISTICS
(Typical Operating Circuit with one attenuator connected, V CC = +4.75V to +5.25V, T A = -40°C to +85°C, unless otherwise noted.
Typical values are at V CC = +5.0V, R1 = 1.2k Ω, R2 = 3.92kΩ, P
OUT = +5dBm, f IN = 900MHz, V CNTL = 1V, 50 Ω system impedance,
second attenuator is not connected, T A = +25°C, unless otherwise noted.) (Note 3)
PARAMETER CONDITIONS MIN TYP MAX UNITS
Frequency Range 800 1000 MHz
Gain T A = +25°C 15.5 dB
V CNTL = 1V +0.82
V CNTL = 1.8V +0.26
V CNTL = 2.6V +0.25
T
A
= +25°C to -40°C
V CNTL = 3.5V -0.18
V CNTL = 1V -0.51
V CNTL = 1.8V -0.11
V CNTL = 2.6V -0.16
Maximum Gain Variation
T A = +25°C to +85°C
V CNTL = 3.5V +0.09
dB
Reverse Isolation 29 dB
Noise Figure (Note 4) 4.5 dB
Output 1dB Compression Point +23.5 dBm
Output 2nd-Order Intercept Point
From maximum gain to 15dB attenuation,
measured at f
1 + f 2 (Note 5)
+54 dBm
Output 3rd-Order Intercept Point From maximum gain to 15dB attenuation (Note 5) +39 dBm
DC ELECTRICAL CHARACTERISTICS
(V CC = +4.75V to +5.25V, no RF signals applied, all input and output ports terminated with 50 Ω, T
A = -40°C to +85°C, unless other-
wise noted. Typical values are at V CC = +5.0V, T A = +25°C, unless otherwise noted.)
PARAMETER CONDITIONS MIN TYP MAX UNITS
Supply Voltage 4.75 5 5.25 V
Supply Current R1 = 1.2k Ω, R2 = 3.92kΩ (Note 1) 136 167 mA
R SET1 Current R1 = 1.2k Ω (Note 1) 1 mA
R SET2 Current R2 = 3.92k Ω (Note 1) 0.33 mA
Gain-Control Voltage Range (Note 2) 1.0 4.5 V
Gain-Control Pin Input Resistance V CNTL = 1V to 4.5V 250 500 k Ω
