Absolute Maximum Ratings
(Notes 1, 2)
Supply Voltage (V
+
)
−0.5 V to 6.0 V
Voltage on Pin 2
−0.3 V to (V+ + 0.3 V)
Voltage on all other Pins
−0.5 V to 6.0 V
Input Current per Pin(Note 3)
5 mA
Package Input Current (Note 3)
30 mA
Package Power Dissipation
Output Sink Current
10 mA
Storage Temperature
−65 ˚C to +150 ˚C
ESD Susceptibility (Note 4)
Human Body Model
2000 V
Machine Model
200 V
Soldering Information, Lead Temperature
MSOP-8 Package (Note 6)
Vapor Phase (60 seconds)
215 ˚C
Infrared (15 seconds)
220 ˚C
Operating Ratings
(Notes 1, 2)
Temperature Range for
Electrical Characteristics
T
MIN
≤ T
A
≤ T
MAX
LM95010CIMM
−20 ˚C
≤ T
A
≤ +125 ˚C
Operating Temperature Range
−20 ˚C
≤ T
A
≤ +125 ˚C
Supply Voltage Range (V+)
+3.0 V to +3.6 V
DC Electrical Characteristics
The following specifications apply for V+ = 3.0 V
DC
to 3.6 V
DC
, unless otherwise specified in the conditions. Boldface limits
apply for T
A
= T
J
= T
MIN
to T
MAX
; all other limits T
A
= +25 ˚C.
POWER SUPPLY CHARACTERISTICS
Symbol
Parameter
Conditions
Typical
Limits
Units
(Limit)
V+
Power Supply Voltage
3.3
3.0
3.6
V (min)
V (max)
I+
AVG
Average Power Supply Current
SensorPath Bus Inactive (Note
500
750
µA (max)
I+
Peak
Peak Power Supply Current
SensorPath Bus Inactive (Note
1.6
mA
Power-On Reset Threshold Voltage
1.6
V (min)
2.8
V (max)
TEMPERATURE-TO-DIGITAL CONVERTER CHARACTERISTICS
Parameter
Conditions
Typical
Limits
Units
(Limits)
Temperature Error
T
A
= −20 ˚C and +125 ˚C (Note 10)
±
1
±
3
˚C (max)
+25 ˚C
≤ T
A
≤ +60 ˚C (Note 10)
±
2
˚C (max)
Temperature Resolution
10
Bits
0.25
˚C
SWD and ADD DIGITAL INPUT CHARACTERISTICS
Symbol
Parameter
Conditions
Typical
Limits
Units
(Limit)
V
IH
SWD Logical High Input Voltage
2.1
V (min)
V+ + 0.5
V (max)
V
IL
SWD Logical Low Input Voltage
0.8
V (max)
T
A
= 0 ˚C to +85 ˚C
-0.5
V (min)
-0.3
V (min)
V
IH
ADD Logical High Input Voltage
90% x V+
V (min)
V
IL
ADD Logical Low Input Voltage
10% x V+
V (max)
V
HYST
SWD Input Hysteresis
300
mV
I
L
SWD and ADD Input Leakage
Current
GND
≤V
IN
≤ V+
±
0.005
±
10
µA (max)
SWD Input Leakage Current with V+
Open or Grounded
GND
≤V
IN
≤ 3.6 V,
and V+ Open or
GND
±
0.005
µA
LM95010
