MAX987/MAX988/MAX991/MAX992/MAX995/MAX996
High-Speed, Micropower, Low-Voltage,
SOT23, Rail-to-Rail I/O Comparators
______________________________________________________________________________________
11
__Ordering Information (continued)
Typical Application Circuit
MAX98_
MAX99_
IN+
0.1
µF
*R
PULL-UP
THRESHOLD DETECTOR
* MAX988/MAX992/MAX996 ONLY
V
IN
OUT
V
CC
V
CC
V
EE
V
REF
IN-
__________________________________________________Tape-and-Reel Information
4.0 ±0.1
0.30 ±0.05
0.8 ±0.05
0.30R MAX.
Bo
K
o
2.2 ±0.1
0.5 RADIUS
TYPICAL
A0
4.0 ±0.1
2.0 ±0.05
1.5 +0.1/-0.0 DIAMETER
1.75 ±0.1
1.0 ±0.1
A
8.0 ±0.3
3.5 ±0.05
1.0 MINIMUM
A
Ao = 3.1mm ±0.1
Bo = 2.7mm ±0.1
Ko = 1.2mm ±0.1
NOTE: DIMENSIONS ARE IN MM. AND
FOLLOW EIA481-1 STANDARD.
PART
TEMP. RANGE
PIN-
PACKAGE
TOP
MARK
MAX988EXK-T
-40°C to +85°C
5 SC70-5
ABN
MAX988EUK-T
-40°C to +85°C
5 SOT23-5
ABZC
MAX988ESA
-40°C to +85°C
8 SO
—
MAX991EKA-T
-40°C to +85°C
8 SOT23-8
AAEB
MAX991EUA
-40°C to +85°C
8
µMAX
—
MAX991ESA
-40°C to +85°C
8 SO
—
MAX992EKA-T
-40°C to +85°C
8 SOT23-8
AAEC
MAX992EUA
-40°C to +85°C
8
µMAX
—
MAX992ESA
-40°C to +85°C
8 SO
—
MAX995EUD
-40°C to +85°C
14 TSSOP
—
MAX995ESD
-40°C to +85°C
14 SO
—
MAX996EUD
-40°C to +85°C
14 TSSOP
—
MAX996ESD
-40°C to +85°C
14 SO
—
