MAX2642/MAX2643
900MHz SiGe, High IP3,
Low-Noise Amplifiers
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS—MAX2642
(V CC = +2.7V to +5.5V, T A = -40°C to +85°C, no RF signal applied, RFIN and RFOUT are AC-coupled and terminated to 50 Ω, high-
gain mode. Typical values are at V CC = 3.0V, T A = +25°C, unless otherwise noted.) (Notes 1, 2, 3)
DC ELECTRICAL CHARACTERISTICS—MAX2643
(V CC = +2.7V to +5.5V, T A = -40°C to +85°C, no RF signal applied, RFIN and RFOUT are AC-coupled and terminated to 50 Ω. Typical
values are at V CC = 3.0V, T A = +25°C, unless otherwise noted.) (Notes 1, 8, 9)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V CC to GND ..............................................................-0.3V to +6V
RFOUT to GND...........................................-0.3V to (V CC + 0.3V)
RFIN to GND ..................................................................0 to 0.9V
RFIN Power (50
Ω source) ................................................+5dBm
BIAS to GND ................................................................0 to +0.3V
Operating Temperature Range ...........................-40°C to +85°C
Maximum Junction Temperature .....................................+150°C
Continuous Power Dissipation (T
A = +70°C)
SC70-6 (derate 3.1mW/°C above +70°C) ...................245mW
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
Supply Voltage 2.7 5.5 V
High-gain mode, R BIAS = 510 Ω, T
A = +25 °C 5.3 6.7
R
BIAS
= 510 Ω, T
A
= -40 °C to +85°C 7.5
R BIAS = 806 Ω 3.6
R
BIAS
= 1.1k Ω 2.8
Operating Supply Current
Low-gain mode, R BIAS = 510 Ω, T
A = 25 °C 5.9
mA
Shutdown Supply Current BIAS = unconnected (see Applications Information) 0.2 mA
High-gain mode (Note 4) 0.6
Gain Control Voltage Input
Low-gain mode (Note 5) 2.0
V
High-gain mode (Note 6) -10 0
Gain Control Input Current
Low-gain mode (Note 7) 0 50
µA
PARAMETER CONDITIONS MIN TYP MAX UNITS
Supply Voltage 2.7 5.5 V
R BIAS = 510 Ω, T
A = +25 °C 5.1 6.5
R BIAS = 510 Ω, T
A = -40 °C to +85°C 7.3
R BIAS = 806 Ω 3.4
Operating Supply Current
R BIAS = 1.1k Ω 2.6
mA
Shutdown Supply Current Shutdown mode (see Applications Information) 0.2 10 µA
Normal operation (Note 10) 2.0
Shutdown Control Input Voltage
Shutdown mode (Note 11) 0.6
V
Normal operation (Note 7) 0 10
Shutdown Control Input Current
Shutdown mode (Note 6) -5 5
µA
