MAX2440/MAX2441/MAX2442
900MHz Image-Reject Receivers
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(V
CC
= +2.7V to +4.8V, no RF signals applied, LNAGAIN = unconnected, V
VCOON
= 2.4V, V
RXON
= V
MOD
= V
DIV1
= 0.45V, PREGND
= GND, T
A
= T
MIN
to T
MAX
. Typical values are at T
A
= +25°C, V
CC
= +3.3V, unless otherwise noted.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Note 1:
≥25°C guaranteed by production test, <25°C guaranteed through correlation to worst-case temperature testing.
Note 2: Calculated by measuring the combined oscillator and prescaler supply current and subtracting the oscillator supply current.
Note 3: Calculated by measuring the combined oscillator and LO buffer supply current and subtracting the oscillator supply current.
Note 4: Calculated by measuring the combined receive and oscillator supply current and subtracting the oscillator supply current.
With LNAGAIN = GND, the supply current drops by 4.5mA.
V
CC
to GND ...........................................................-0.3V to +5.5V
Voltage on LNAGAIN, RXON, VCOON,
DIV1, MOD .............................................-0.3V to (V
CC
+ 0.3V)
RXIN Input Power..............................................................10dBm
TANK, TANK Input Power ...................................................2dBm
Continuous Power Dissipation (T
A
= +70°C)
SSOP (derate 9.50mW/°C above +70°C) ....................762mW
Operating Temperature Range
MAX244_EAI ...................................................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +165°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER
MIN
TYP
MAX
UNITS
Receive Supply Current
23
36
mA
Prescaler Supply Current
(buffer mode)
5.4
8.5
mA
Oscillator Supply Current
Supply-Voltage Range
2.7
4.8
V
9.5
14
mA
Prescaler Supply Current
(divide-by-64/65 mode)
4.2
6
mA
CONDITIONS
V
RXON
= 2.4V, PREGND = unconnected (Note 4)
V
DIV1
= 2.4V (Note 3)
PREGND = unconnected
(Note 2)
Digital Input Voltage Low
0.45
V
0.5
RXON, DIV1, VCOON, MOD
VCOON = RXON = MOD =
DIV1 = GND
Digital Input Current
±1
±10
µA
Voltage on any one digital input = V
CC
or GND
Digital Input Voltage High
V
2.4
RXON, DIV1, VCOON, MOD
Shutdown Supply Current
10
µA
T
A
= +25°C
T
A
= T
MIN
to T
MAX
