Typical Application Circuits
In the application circuits, the 0.1 µF ceramic capacitor
between pins 1 and 8 is used for bypassing, and the 0.1
µF ceramic capacitor between pins 3 and 4 is used for fil-
tering. Shutdown (SD) is tied to V
DD
through a 10 k
Ω
resistor.
10012205
FIGURE 1. High Side Sense
10012206
FIGURE 2. Low Side Sense
LM3812/LM3813
www.national.com
7
