MAX1553/MAX1554

High-Efficiency, 40V Step-Up
Converters for 2 to 10 White LEDs

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

CC

= 3.3V, V

OV

= 0V, C

OUT

= 1µF, R

SENSE

= 10

Ω, T

A

= 0°C to +85°C, unless otherwise noted. Typical values are at T

A

= +25

°C.)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V

CC

, FB, OV to GND..............................................-0.3V to +6.0V

LX to GND ..............................................................-0.3V to +45V
EN, BRT, SS to GND...................................-0.3V to (V

CC

+ 0.3V)

I

LX

...................................................................................0.9A

RMS

Continuous Power Dissipation (T

A

= +70°C)

8-Pin 3mm x 3mm TDFN
(derate 24.4mW/°C above +70°C) .............................1951mW

Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

CONDITIONS

MIN

TYP

MAX

UNITS

MAX1553

2.7

5.5

Supply Voltage

MAX1554

3.15

5.50

V

Undervoltage Lockout Threshold

V

CC

rising or falling, 35mV hysteresis typical

2.35

2.5

2.65

V

Not switching

0.33

0.65

Quiescent Current

Switching

0.44

0.9

mA

T

A

= +25°C

0.1

1

Shutdown Supply Current

V

EN

= 0V

T

A

= +85°C

1

µA

OV Threshold

Rising edge

1.18

1.25

1.33

V

T

A

= +25°C

1

200

OV Input Bias Current

V

OV

= 1V

T

A

= +85°C

10

nA

BRT Input Resistance

0 < V

BRT

< 1.5V, EN = V

CC

200

400

600

k

TIMING CONTROL

Maximum On-Time

V

CC

= 3.3V

2.0

3.4

4.8

µs

On-Time Constant (K)

t

ON

= K / V

CC

6.3

µs-V

Minimum Off-Time

150

250

350

ns

ERROR AMPLIFIER

V

BRT

= 1.25V

192

203

212

FB Threshold

V

BRT

= 3.3V

280

mV

T

A

= +25°C

15

200

FB Input Bias Current

V

FB

= 1.0V

T

A

= +85°C

100

nA

N-CHANNEL SWITCH

LX On-Resistance

0.8

1.4
