Package Information (continued)
(The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information,
DOCUMENT CONTROL NO.
APPROVAL
TITLE:
PROPRIETARY INFORMATION
REV.
2
2
COMMON DIMENSIONS
SYMBOL
MIN.
MAX.
A
0.70
0.80
D
2.90
3.10
E
2.90
3.10
A1
0.00
0.05
L
0.20
0.40
PKG. CODE
6
N
T633-1
1.50–0.10
D2
2.30–0.10
E2
0.95 BSC
e
MO229 / WEEA
JEDEC SPEC
0.40–0.05
b
1.90 REF
[(N/2)-1] x e
1.50–0.10
MO229 / WEEC
1.95 REF
0.30–0.05
0.65 BSC
2.30–0.10
T833-1
8
PACKAGE VARIATIONS
21-0137
0.25–0.05
2.00 REF
MO229 / WEED-3
0.50 BSC
1.50–0.10
2.30–0.10
10
T1033-1
0.25 MIN.
k
A2
0.20 REF.
D
SEMICONDUCTOR
DALLAS
PACKAGE OUTLINE, 6, 8 & 10L,
TDFN, EXPOSED PAD, 3x3x0.80 mm
