MAX1098/MAX1099
10-Bit Serial-Output Temperature Sensors
with 5-Channel ADC
________________________________________________________________________________________ 9
Typical Operating Characteristics (continued)
(T
A
= +25°C, unless otherwise noted.)
-1.0
-0.5
0
0.5
1.0
-60 -20 20 60 -40 0 40 80 100
MAX1099
TEMPERATURE ERROR
vs. INTERNAL DIODE TEMPERATURE
MAX1098/9-30
TEMPERATURE ( °C)
TEMPERATURE ERROR (
°C)
-2.0
-1.0
-1.5
0
-0.5
0.5
1.0
1.5
2.0
-60 -20 0 -40 20 40 60 80 100
MAX1098
TEMPERATURE ERROR
vs. REMOTE DIODE TEMPERATURE
MAX1098/9-31
TEMPERATURE ( °C)
TEMPERATURE ERROR (
°C)
-2.0
-1.0
-1.5
0
-0.5
0.5
1.0
1.5
2.0
-60 -20 0 -40 20 40 60 80 100
MAX1099
TEMPERATURE ERROR
vs. REMOTE DIODE TEMPERATURE
MAX1098/9-32
TEMPERATURE ( °C)
TEMPERATURE ERROR (
°C)
