General Description
The MAX1098/MAX1099 implement both local and
remote temperature sensing with 10-bit resolution,
using +5V and +3V supply voltages, respectively.
Accuracy is ±1°C from 0°C to +70°C, with no calibra-
tion needed. The devices feature an algorithmic
switched-capacitor analog-to-digital converter (ADC),
on-chip clock, and 3-wire serial interface compatible
with SPI™, QSPI™, and MICROWIRE™.
The MAX1098/MAX1099 also perform fully differential
voltage measurements with 10-bit resolution and sepa-
rate track-and-hold (T/N) for positive and negative
inputs. Both devices accept versatile input modes con-
sisting of two 3-channel signal pairs, five 1-channel sig-
nals relative to a floating common, or V
DD /4 relative to
ground. An external reference may be used for more
accurate voltage measurements.
Typical power consumption is only 1.3mW (MAX1099).
A shutdown mode and two standby modes provide
multiple strategies for prolonging battery life in portable
applications that require limited sampling throughput.
The MAX1098/MAX1099 are available in 16-pin SSOP
packages.
Applications
Temperature/Voltage Supervision of
Workstations and Communications Equipment
Hand-Held Instruments
Medical Equipment
Industrial Process Control
Features
♦ Local and Remote Temperature Sensing
♦ 12-Bit Resolution for Temperature and
10-Bit Resolution for Voltage Inputs
♦ ±1°C Accuracy from -40°C to +85°C
♦ Fully Differential Inputs
♦ Single-Supply Operation
+4.75V to +5.25V (MAX1098)
+2.7V to +3.6V (MAX1099)
♦ 3-Wire SPI/QSPI/MICROWIRE-Compatible
Interface
♦ Internal Precision Voltage Reference
2.50V (MAX1098)
1.20V (MAX1099)
♦ Space-Saving 16-Pin SSOP Package
MAX1098/MAX1099
10-Bit Serial-Output Temperature Sensors
with 5-Channel ADC
________________________________________________________________ Maxim Integrated Products 1
16
15
14
13
12
11
10
9
1
2
3
4
5
6
7
8
AIN1 AIN0
AIN5
REF
GND
V DD
SCLK
DIN
COUT
TOP VIEW
MAX1098
MAX1099
SSOP
SHO
AIN2
GND
AIN3
AIN4
SSTRB
CS
Pin Configuration
19-1728; Rev 0; 7/00
For free samples and the latest literature, visit www.maxim-ic.com or phone 1-800-998-8800.
For small orders, phone 1-800-835-8769.
Ordering Information
*Future product—contact factory for availability.
Typical Operating Circuit appears at end of data sheet.
SPI and QSPI are trademarks of Motorola, Inc.
MICROWIRE is a trademark of National Semiconductor Corp.
PART
TEMP.
RANGE
PIN-
PACKAGE
TEMP. SENSE
ACCURACY
( °C)
MAX1098AEAE* -40 °C to +85°C 16 SSOP ±0.75
MAX1098BEAE* -40 °C to +85°C 16 SSOP ±1.0
MAX1098CEAE -40 °C to +85°C 16 SSOP ±4.0
MAX1099AEAE* -40 °C to +85°C 16 SSOP ±0.75
MAX1099BEAE* -40 °C to +85°C 16 SSOP ±1.0
MAX1099CEAE -40 °C to +85°C 16 SSOP ±4.0
-1.0
-0.5
0
0.5
1.0
-60 -20 20 60 -40 0 40 80 100
MAX1098
TEMPERATURE ERROR
vs. INTERNAL DIODE TEMPERATURE
MAX1098/9-29
TEMPERATURE ( °C)
TEMPERATURE ERROR (
°C)
Temperature Error
