Ds1807 ordering information – Rainbow Electronics DS1807 User Manual
Page 13
DS1807
13 of 13
110499
TIMING DIAGRAM Figure 8
INTERNAL GROUND CONNECTIONS Figure 9
NOTE: GND and AGND must be tied to the same voltage level.
DS1807 ORDERING INFORMATION
ORDERING
NUMBER
PACKAGE
OPERATING
TEMPERATURE
VERSION
DS1807
14L DIP
-40°C TO +85°C
45K
Ω
DS1807E
14L TSSOP (173-MIL)
-40°C TO +85°C
45K
Ω
DS1807S
16L SOIC (300- MIL)
-40°C TO +85°C
45K
Ω
