Rainbow Electronics BU4081BFV User Manual
Quad 2-input and gate, Standard ics
1
Standard ICs
Quad 2-input AND gate
BU4081B / BU4081BF / BU4081BFV
The BU4081B, BU4081BF, and BU4081BFV are dual-input positive-logic AND gates with four circuits mounted on a
single chip. An inverter-type buffer is added to the gate output, improving input / output transmission speed, and an
increased load capacitance suppresses fluctuation in transmission time to a minimum.
•
Features
1) Low power dissipation.
2) Wide range of operating power supply voltages.
3) High input impedance.
4) High fan-out.
5) Direct drive of 2 L-TTL inputs and 1 LS-TTL input.
•
Logic circuit diagram
V
DD
OUT
V
SS
IN
IN
•
Block diagram
1
A
1
2
B
1
3
O
1
4
O
2
5
B
2
6
A
2
7
14
13
12
11
10
9
8
V
SS
V
DD
A
4
B4
O
4
O
3
B
3
A
3
