Standard ICs
Quad exclusive OR gate
BU4030B / BU4030BF
BU4070B / BU4070BF
The BU4030B / F and BU4070B / F are exclusive OR gates.
Four circuits are contained on a single chip. An inverter-based buffer is added to the gate output for an enhanced I / O
voltage characteristic, and the load capacitance has been increased to minimize fluctuation in the propagation time.
In addition, these products feature low power consumption and a high noise margin.
These can also be used in digital comparators and parity circuit applications.
•
Truth table
•
Absolute maximum ratings (V
SS
= 0V, Ta = 25°C)
INPUT
OUTPUT
A
B
L
L
L
L
H
H
H
L
H
H
H
L
•
Block diagram
A
1
1
B
1
2
O
1
3
O
2
4
B
2
5
A
2
6
V
SS
7
11
14 V
DD
13 A
4
12 B
4
O
4
10 O
3
9
B
3
8
A
3
Parameter
Symbol
Limits
Unit
Power supply voltage
V
DD
V
Power dissipation
mW
Operating temperature
– 40 ~ + 85
°
C
Storage temperature
– 55 ~ + 150
°
C
Input voltage
V
IN
V
– 0.3 ~ + 18
– 0.3 ~ V
DD
+ 0.3
1000 (DIP), 450 (SOP)
Pd
Topr
Tstg
•
Features
1) Low power dissipation.
2) Wide range of operating power supply voltages.
3) High input impedance.
4) High fan-out.
5) Direct drive of 2 L-TTL inputs and 1 LS-TTL input.
