ISD1916
Publication Release Date: September 11, 2007
- 17 - Revision 0
7. ABSOLUTE MAXIMUM RATINGS [1]
ABSOLUTE MAXIMUM RATINGS
CONDITION VALUE
Junction temperature 150°C
Storage temperature range -65°C to +150°C
Voltage applied to any pins (V
SS
– 0.3V) to (V
CC
+ 0.3V)
Voltage applied to Input pins (current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
Voltage applied to output pins (current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
V
CC
– V
SS
-0.3V to +7.0V
[1] Stresses above those listed may cause permanent damage to the device. Exposure to the
absolute maximum ratings may affect device reliability and performance. Functional operation is
not implied at these conditions.
7.1 O PERATING C ONDITIONS
OPERATING CONDITIONS
CONDITION VALUE
Operating temperature range 0°C to +50°C
Operating voltage (V
CC
) [1] +2.4V to +5.5V
Ground voltage (V
SS
) [2] 0V
[1] V
CC
= V
CCA
= V
CCD
[2] V
SS
= V
SSA
= V
SSD
